Remove the Rear I/O Module
176 SPARC T5-4 Server Service Manual • July 2016
1.
Determine if the System Service Required LED is illuminated on the rear I/O
module.
See “Rear I/O Module LEDs” on page 173.
2.
Remove the faulty rear I/O module.
See “Remove the Rear I/O Module” on page 176.
Related Information
■
“Rear I/O Module LEDs” on page 173
■
“Remove the Rear I/O Module” on page 176
■
“Install the Rear I/O Module” on page 178
■
“Verify the Rear I/O Module” on page 180
Remove the Rear I/O Module
The rear I/O module is a cold-service component that can be replaced by a customer.
1.
Take the necessary ESD precautions.
See “Prevent ESD Damage” on page 54.
2.
Locate the failed rear I/O module.
■
See “Rear Panel Components” on page 15 for the location of the rear I/O
module in the server.
■
See “Determine if the Rear I/O Module Is Faulty” on page 175 to verify that
the rear I/O module has failed.
3.
Power off the server.
See “Removing Power From the Server” on page 51.
4.
Disconnect the power cords.
See “Disconnect Power Cords” on page 53.
5.
Label the cables connected to the ports on the rear I/O module, and then
disconnect the cables from the ports.
You will reconnect the cables to the same ports on the replacement rear I/O module.
