8. TECHNOLOGY
The innovative technology of the MYTHIC 22 is covered by six pending patents. A new innovative concept of
optical measurement system and a unique lysing reagent were developed to obtain a small and powerful
analyzer.
8.1 DETECTION PRINCIPLE
8.1.1 WBC, RBC, PLT Counting
The counting of the cellular elements in a blood sample is done with the impedance technique.
This technique is based on the modification of the impedance of a calibrated aperture soaking in an
electrolyte and going through a constant course delivered by two electrodes, located on both sides of the
aperture.
A vacuum applied on a side of the aperture allows the cells passage. They oppose their physical volume to the
course passage. A voltage impulse is registered at the electrodes terminal. The height of this impulse is
proportional to the cell volume.
Aperture
Electrode
Detection area
Proportional height to the cell volume
Voltage impulse et the electrode terminal
Counting Impulse
