8.6.5 Optical bench
This very important part (two pending patents) allows to measure the leucocytes sub population.
It is made of three parts:
- An illumination module: which contain the semiconductor light source, a beam adjustment glass smear and
lens.
- A flow cell: made in injected plastic in which the sample and the passive sheath flow away.
- And the detection module: which contains lens, a beam separation glass smear, photodiodes and the
amplifier boards for the two measurement axes.
8.7 SOFTWARE
8.7.1 Windows
Common keys:
These three keys are always present in all screen.
allows to come back to the previous display.
allows to come back to the MENU display where ever you are in the arborescence.
depends on the screen, it allows to open a window dedicated to perform an action, for example to
select information, to print, send or delete it.
Windows:
occurred, it is mandatory
to do the action described
in the window or in the
confirm or not the action
described in the window.
