- This screen allows checking if the different sensors are available in case of
problem.
NOTA: To understand the function of each sensor we recommend to do
an Orphée’s training.
- Range of standard temperature measured by the sensors:
Ambient: 17°C <--> 37°C,
Enclosure: 33°C <--> 40°C,
Reagents: 34°C <--> 45°C.
-Range of vacuum pressure: 410 mbar +/-15 (depend of altitude).
- To test each valve, press the dedicated button.
- To test all the valves press .
9.4 REPAIRING
9.4.1 Emergency stop
In case of mechanical or hydraulic problem, immediately press , the MYTHIC 22 will make an emergency
stop.
- After having identified the problem, it is necessary to perform a control
cycle.
- To have access to this cycle, press from the MAIN
MENU, then press .
