Check the Installation and Maintenance kit contents:
INSTALLATION KIT
QTY
Designation
Part Number
1
M22- DILUENT
005-1002-90 23 -01
1
M18 - WASTE
005-1011-90 24
1
150W switching adapter
050-1001-01 150 24
1
European Power line cord
150-2001-CEE C13 1000
2
5/10-20L Adaptator
300-1009-05 1020
1
M22C User manual
N/C
1
MYTHIC 22 Installation Report
N/C
1
MYTHIC 22 Quality Control Certificate
N/C
1
Screwdriver Slot 1/4"
700-7101-02
MAINTENANCE KIT Box 18/22
QTY
Designation
Part Number
1
Tygon tubing 1.52x3.2mm(1000mm)
300-0502- 016 032
1
Tygon tubing 2.06x4mm(500mm)
300-0502-020 040
1
Tygon tubing 1.02x2.7mm(500mm)(for Mythic
22)
300-0502-010
1
Tygon tubing 1.3x3mm(500mm)
300-0502-013 030
1
Tubing 9 1.3x3mm (425mm)
N/C
1
Tubing 10 M22 0.9 x2.4 (500mm)
N/C
1
Tubing 10 M18 0.9 x 2.4 (375mm)
N/C
1
Tubing 50 (for Mythic 22)
005-1002-90-50
5
Cables Ties
153-0101-100 25
1
O-Ring 1.4x1.25mm, needle O-ring
312-0505-1310 160
2
O-ring 5x1mm, Counting heads O-rings
312-0505-140 125 010
2
O-rings 13.1x1.6mm, Counting baths O-rings
312-0505-500 100
1
1L flexible straw
005-1001-06 02
1
Silicon grease (3gr)
410-0501-02 02
1
Short Arm TORX T10 Tool
700-1101-10
1
Short Arm TORX T20 Tool
700-1101-20
