- Draw the system towards outside 2 .
-
Unscrew the serrated roller which maintains the seal and the
needle.
- Leave the serrated roller, the needle and the o-
rinsing head.
- Remove the o-ring.
- Replace the o-ring. No greasing.
REASSEMBLY PROCEDURE:
To reassemble the unit, carry out the various operations in the opposite direction. Place the seal on the
needle gently not to wound it.
