Handbook
November 2011 / 59-UMC0071 / Issue 01
Mercury iTC
Page 109
COMMAND REFERENCE GUIDE
Original Instructions
The signals for a temperature sensor are:
NOTE: The signals that are available depend on the type of sensor being addressed. If
a signal is unavailable, the message INVALID is returned.
Example of configuring a temperature sensor
The following command configures a temperature sensor:
SET:DEV:MB0 :TEMP:TYPE:PTC:EXCT:TYPE:UNIP:MAG:10uA:CALB:RP5:DAT
If this command is successfully completed, the following message is returned:
STAT:SET:DEV:MB0
:TEMP:TYPE:PTC:EXCT:TYPE:UNIP:MAG:10uA:CALB:RP5:DAT
If the excitation type is not supported, the following message is returned:
STAT:SET:DEV:MB0 :TEMP:TYPE:PTC:EXCT:TYPE:INVALID:MAG:INVALID:
CALB:RP5:DAT
NOTE: All the new settings that are valid are set. All the new settings that are invalid
are not changed.
TYPE Excitation type [UNIP | BIP | SOFT] Read/set Enumerated set
MAG Excitation magnitude Read/set Float value followed
by a scale
CAL Calibration designator N/A
FILE Calibration file name Read/set Filename
INT Interpolation type [LIN | SPL | LAGR] Read/set Enumerated set
SCAL Scaling factor Read/set Float value
[0.5 to 1.5]
OFFS Offset value Read/set Float value
[-100.0 to 100.0]
HOTL Hot limit Read only Float value
COLD Cold limit Read only Float value
VOLT Most recent voltage reading Read only Float value
CURR Most recent current reading Read only Float value
POWR Most recent power reading Read only Float value
RES Most recent resistance reading Read only Float value
TEMP Most recent temperature reading Read only Float value
SLOP Temperature sensitivity Read only Float value
