14-9
FP0
Item
Add-
ress
Name
Default
value
Descriptions
Input
setting
400
High-
speed
counter
mode
settings
(X0 to X2)
Setting
by FP
pro-
grammer
II
H0
CH0/
CH1
Note1) If the operation mode is set to 2-phase, individual, or direction differentiation, the setting for CH1
is invalid.
Note2) If reset input settings overlap, the setting of CH1 takes precedence.
Note3) If system register 400 to 403 have been set simultaneously for the same input relay, the following
precedence order is effective: [High-speed counter] ‘[Pulse catch]’ [Interrupt input].
