14-22
Address
FP0 T32
FP0 C10,
C14, C16,
C32, SL1
Name Descriptions
DT90038 DT9038
Work 2 for F96 (SRC)
instruction
The position of the first matching data, counting
from the starting 16-bit area, is stored here when
an F96 (SRC) instruction is executed.
DT90039
to
DT90043
DT9039
to
DT9043
Not used
-
DT90044 DT9044
DT90045 DT9045
High-speed counter
elapsed value for ch0
The elapsed value (24-bit data) for the high-
speed counter is stored here. Each time the ED
instruction is executed, the elapsed value for the
high-speed counter is automatically transferred
to the special registers DT9044 and
DT9045/DT90044 and DT90045.
The value can be written by executing F1 (DMV)
instruction.
DT90046 DT9046
DT90047 DT9047
High-speed counter
target value for ch0
The target value (24-bit data) of the high-speed
counter specified by the high-speed counter
instruction is stored here.
Target values have been preset for the various
instructions, to be used when the high-speed
counter related instruction F166 to F170 is
executed. These preset values can only be read,
and cannot be written.
DT90048 DT9048
DT90049 DT9049
High-speed counter
elapsed value area for
ch1
The elapsed value (24-bit data) for the high-
speed counter is stored here. Each time the ED
instruction is executed, the elapsed value for the
high-speed counter is automatically transferred
to the special registers DT9048 and
DT9049/DT90048 and DT90049.
The value can be written by executing F1 (DMV)
instruction.
DT90050 DT9050
DT90051 DT9051
High-speed counter
target value area for
ch1
The target value (24-bit data) of the high-speed
counter specified by the high-speed counter
instruction is stored here.
Target values have been preset for the various
instructions, to be used when the high-speed
counter related instruction F166 to F170 is
executed. These preset values can only be read,
and cannot be written.
