14-124
Table of Syntax Check Error
Error
code
Name
Opera-
tion
status
Description and steps to take
FP0
FP-e
FPΣ
FP-X
FP1/FP-M
FP2
FP2SH
FP10SH
FP3
E1
Syntax
error
Stops
A program with a syntax error has been
written.
⇒ Change to PROG. mode and correct
the error.
AAAAA A A A A
E2
(Note)
Duplicated
output
error
Stops
Two or more OT(Out) instructions and
KP(Keep) instructions are programmed
using the same relay.Also occurs when
using the same timer/counter number.
⇒ Change to PROG. mode and correct
the program so that one relay
is not used for two or more OT
instructions,Or, set the duplicated output
to “enable” in system register20. A
timer/counter instructon double definition
error will be detected even if double
output permission has been selected.
AAAAA A A A A
E3
Not paired
error
Stops
For instructions which must be used in a
pair such as jump (JP and LBL), one
instruction is either missing or in an
incorrect position.
⇒ Change to PROG. mode and enter
the two instructions which must
be used in a pair in the correct positions.
AAAAA A A A A
E4
Para-meter
mismatch
error
Stops
An instruction has been written which
does not agree with system register
settings. For example, the number
setting in a program does not agree with
the timer/counter range setting.
⇒ Change to PROG. mode, check the
system register settings, and change so
that the settings and the instruction
agree.
AAAAA A A A A
E5
(Note)
Program
area error
Stops
An instruction which must be written in a
specific area (main program area or
subprogram area) has been written to a
different area (for example, a subroutine
SUB to RET is placed before an ED
instruction).
⇒ Change to PROG. mode and enter
the instruction into the correct area.
AAAAA A A A A
A:Available
Note) This error is also detected if you attempt to execute a rewrite containing a syntax error during RUN.
In this case, nothing will be written to the CPU and operation will continue.
