Panasonic LP-310 - Marking Status Transmission Commands; Marking Status Transmission Permission; Error Codes During Marking

185
7. Marking status transmission permission (code: MST)
(1) Marking status transmission permission setting
This command sets the transmission permission/prohibition of the response indicating the laser marker
status at the end of the marking. Note that the transmission permission/prohibition data is initialized into
“transmission prohibition” after turning OFF the power supply of the laser marker.
As for the response data, either normal reception response data or abnormal reception response data is
returned.
Refer to “Response Data” (P.174) for details of both normal reception response data and abnormal recep-
tion response data.
(2) Marking status transmission permission setting readout
This command reads out the response transmission permission/prohibition.
As for the response data, either normal reception response data or abnormal reception response data is
returned.
Refer to “Response Data” (P.174) for details of the abnormal reception response data.

Readout response data
Description of data
Data transmission after setting marking status transmission permission
If the marking trigger signal from the external I/O and the marking trigger command through the
communication control are accepted after the marking status transmission permission is set, the status is
set after the marking operation is finished.

Readout data
Description of data
Error code during marking operation
Name
Data
length
Outline Content
Transmission
permission/
prohibition
1
Indicates the permission/prohibition of the
response transmission.
“0”•••Transmission prohibited
“1”•••Transmission permitted
Name
Data
length
Outline Content
Status 2
Indicates the status during marking
operation.
“00”•••Finished marking normally
Others•••Occurred error code
during marking operation
Indication Status Description
- 00 Normal marking operation
E04 04 No setting file
E10 10 Under marking Remote interlock connector OPEN
E11 11 Under marking Laser radiation stop input
E12 12 Under marking Shutter operated
E20 20 Cover OPEN
E21
E22
21
22
X/Y galvanometers error
E23 23 Laser error
E25 25 Marking file error
E26 26 Area over
STX MST S [Transmission perm. / proh.] (1 Byte) (Check sum) Delimiter
STX MST R (Check sum) Delimiter
STX MST A [Transmission perm. / proh.] (1 Byte) (Check sum) Delimiter
STX MST A [Status] (2 Bytes) Check sum Delimiter
