184
5. Status request (code: STS)
(1) Status request
This command reads out the operation status of the laser marker.
As for the response data, either normal reception response data or abnormal reception response data is
returned.
Refer to “Response Data” (P.174) for details of the abnormal reception response data.
Status request response
Description of data
6. Marking trigger (code: MRK)
(1) Marking trigger
This command marks the file under selected by file number change command (FNO) once.
As for the response data, either normal reception response data or abnormal reception response data is
returned.
Refer to “Response Data” (P.174) for details of both normal reception response data and abnormal recep-
tion response data.
Name
Data
length
Outline Content
Ready 1 Indicates the marking ready status.
“0”•••Marking busy
“1”•••Marking ready
Shutter 1 Indicates the shutter lever status.
“0”•••Shutter closed
“1”•••Shutter opened
Interlock
connector
1 Indicates the interlock connector status.
“0”•••Interlock occurred
“1”••• No interlock occurred
Laser radiation
stop
1
Indicates the laser radiation stop input of the
I/O connector.
“0”•••Laser radiation stop: OFF
“1”•••Laser radiation stop: ON
Counter end 1
Indicates the counter current value is reached
to the counter end value.
“0”•••Current value<end value
“1”•••Current value = end value
Error occurred
status
1 Indicates the error is occurred.
“0”•••Error occurred
“1”•••No error occurred
STX STS R
(Check sum)
Delimiter
STX STS A Data (6 Bytes)
(Check sum)
Delimiter
Ready Shutter Interlock connector Laser radiation
stop
Counter end Error occurred
status
STX MRK S
(Check sum)
Delimiter
To Next Page
