Programming Your Application 1-127
690+ Series Frequency Inverter
Value Func 15
OUTPUT [1319]
–
0.00
0.00 – [1316] INPUT A
–
0.00
–
[1317] INPUT B
–
0.00
–
[1318] INPUT C
–
IF(C) -
A
–
[1320] TYPE
–
Value Func 17
OUTPUT [1329]
–
0.00
0.00 – [1326] INPUT A
–
0.00
–
[1327] INPUT B
–
0.00
–
[1328] INPUT C
–
IF(C) -
A
–
[1330] TYPE
–
Value Func 19
OUTPUT [1339]
–
0.00
0.00 – [1336] INPUT A
–
0.00
–
[1337] INPUT B
–
0.00
–
[1338] INPUT C
–
IF(C) -
A
–
[1340] TYPE
–
Value Func 16
OUTPUT [1324]
–
0.00
0.00 – [1321] INPUT A
–
0.00
–
[1322] INPUT B
–
0.00
–
[1323] INPUT C
–
IF(C) -
A
–
[1325] TYPE
–
Value Func 18
OUTPUT [1334]
–
0.00
0.00 – [1331] INPUT A
–
0.00
–
[1332] INPUT B
–
0.00
–
[1333] INPUT C
–
IF(C) -
A
–
[1335] TYPE
–
Value Func 20
OUTPUT [1344]
–
0.00
0.00 – [1341] INPUT A
–
0.00
–
[1342] INPUT B
–
0.00
–
[1343] INPUT C
–
IF(C) -
A
–
[1345] TYPE
–
Boolean inputs and outputs are
Outputs: FALSE = 0.00, TRUE = 0.01
Inputs: -0.005 < x < 0.005 = FALSE, Else TRUE
TYPE
Range: Enumerated - see below
The operation to be performed on the three inputs to produce the output value.
Enumerated Value : Type Enumerated Value : Type
0 : IF(C) -A
1 : ABS(A+B+C)
2 : SWITCH(A,B)
3 : (A*B)/C
4 : A+B+C
5 : A-B-C
6 : B<=A<=C
7 : A>B+/-C
8 : A>=B
9 : ABS(A)>B+/-C
10 : ABS(A)>=B
11 : A(1+B)
12 : IF(C) HOLD(A)
13 : BINARY DECODE
14 : ON DELAY
15 : OFF DELAY
16 : TIMER
17 : MINIMUM PULSE
18 : PULSE TRAIN
19 : WINDOW
20 : UP/DWN COUNTER
21 : (A*B)/C ROUND
22 : WINDOW NO HYST
23 : WINDOW B<=A<=C
24 : A<=B
25 : ((A*B)/100) + C
26 : MIN (A,B,C)
27 : MAX (A,B,C)
28 : PROFILE SQRT
29 : PROFILE LINEAR
30 : PROFILE X^2
31 : PROFILE X^3
32 : PROFILE X^4
OUTPUT
Range: —.xx
The result of performing the selected operation on the inputs.
Parameter Descriptions
INPUT A
Range: -32768.00 to 32767.00
General purpose input.
INPUT B
Range: -32768.00 to 32767.00
General purpose input.
INPUT C
Range: -32768.00 to 32767.00
General purpose input.
