2-12 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block
1270 TIME LIMIT POWER LOSS CNTRL
582 TIMEOUT INJ BRAKING
1584 TOLERANCE PHASE AUTO GEAR
1202 TORQ DMD ISOLATE SPEED LOOP
1204 TORQUE DEMAND SPEED LOOP
788 TORQUE DEMAND TORQUE CALC
70 TORQUE FEEDBACK FEEDBACKS
789 TORQUE LIMIT TORQUE CALC
1697 TOTAL HOURS TIMER 1
1827 TOTAL HOURS TIMER 2
1698 TOTAL SECONDS TIMER 1
1828 TOTAL SECONDS TIMER 2
1206 TOTAL SPD DMD % SPEED LOOP
1203 TOTL SPD DMD RPM SPEED LOOP
609 TRIGGERS 1 AUTO RESTART
744 TRIGGERS 1+ AUTO RESTART
677 TRIGGERS 2 AUTO RESTART
745 TRIGGERS 2+ AUTO RESTART
243 TRIM IN LOCAL REFERENCE
500 TRIP 1 (NEWEST) TRIPS HISTORY
509 TRIP 10 (OLDEST) TRIPS HISTORY
501 TRIP 2 TRIPS HISTORY
502 TRIP 3 TRIPS HISTORY
503 TRIP 4 TRIPS HISTORY
504 TRIP 5 TRIPS HISTORY
505 TRIP 6 TRIPS HISTORY
506 TRIP 7 TRIPS HISTORY
507 TRIP 8 TRIPS HISTORY
508 TRIP 9 TRIPS HISTORY
290 TRIP RST BY RUN SEQUENCING LOGIC
1266 TRIP THRESHOLD POWER LOSS CNTRL
289 TRIPPED SEQUENCING LOGIC
1650 TRIPPED SPD FBK TRIP
13 TYPE ANALOG INPUT 1
22 TYPE ANALOG INPUT 2
712 TYPE ANALOG INPUT 3
719 TYPE ANALOG INPUT 4
49 TYPE ANALOG OUTPUT 1
735 TYPE ANALOG OUTPUT 2
804 TYPE ANALOG OUTPUT 3
184 TYPE LOGIC FUNC 1
229 TYPE LOGIC FUNC 10
1350 TYPE LOGIC FUNC 11
1355 TYPE LOGIC FUNC 12
1360 TYPE LOGIC FUNC 13
1365 TYPE LOGIC FUNC 14
1370 TYPE LOGIC FUNC 15
1375 TYPE LOGIC FUNC 16
1380 TYPE LOGIC FUNC 17
1385 TYPE LOGIC FUNC 18
1390 TYPE LOGIC FUNC 19
189 TYPE LOGIC FUNC 2
1395 TYPE LOGIC FUNC 20
194 TYPE LOGIC FUNC 3
199 TYPE LOGIC FUNC 4
204 TYPE LOGIC FUNC 5
209 TYPE LOGIC FUNC 6
214 TYPE LOGIC FUNC 7
219 TYPE LOGIC FUNC 8
224 TYPE LOGIC FUNC 9
750 TYPE TEC OPTION
134 TYPE VALUE FUNC 1
179 TYPE VALUE FUNC 10
1300 TYPE VALUE FUNC 11
1305 TYPE VALUE FUNC 12
1310 TYPE VALUE FUNC 13
TAG MMI Name Block
1315 TYPE VALUE FUNC 14
1320 TYPE VALUE FUNC 15
1325 TYPE VALUE FUNC 16
1330 TYPE VALUE FUNC 17
1335 TYPE VALUE FUNC 18
1340 TYPE VALUE FUNC 19
139 TYPE VALUE FUNC 2
1345 TYPE VALUE FUNC 20
144 TYPE VALUE FUNC 3
149 TYPE VALUE FUNC 4
154 TYPE VALUE FUNC 5
159 TYPE VALUE FUNC 6
164 TYPE VALUE FUNC 7
169 TYPE VALUE FUNC 8
174 TYPE VALUE FUNC 9
103 UNIT ID (UID) SYSTEM PORT (P3)
323 UNITS DISPLAY SCALE 1
377 UNITS DISPLAY SCALE 2
859 UNITS DISPLAY SCALE 3
867 UNITS DISPLAY SCALE 4
1151 UP TIME INVERSE TIME
785 UP TO SPD (UTS) SPEED CALC
1657 USER FREQ 1 FLUXING
1676 USER FREQ 10 FLUXING
1659 USER FREQ 2 FLUXING
1661 USER FREQ 3 FLUXING
1664 USER FREQ 4 FLUXING
1666 USER FREQ 5 FLUXING
1668 USER FREQ 6 FLUXING
1670 USER FREQ 7 FLUXING
1672 USER FREQ 8 FLUXING
1674 USER FREQ 9 FLUXING
1658 USER VOLTAGE 1 FLUXING
1660 USER VOLTAGE 2 FLUXING
1663 USER VOLTAGE 3 FLUXING
1665 USER VOLTAGE 4 FLUXING
1667 USER VOLTAGE 5 FLUXING
1669 USER VOLTAGE 6 FLUXING
1671 USER VOLTAGE 7 FLUXING
1673 USER VOLTAGE 8 FLUXING
1675 USER VOLTAGE 9 FLUXING
777 UTS THRESHOLD SPEED CALC
104 V/F SHAPE FLUXING
1263 VALUE 5703 OUTPUT
16 VALUE ANALOG INPUT 1
25 VALUE ANALOG INPUT 2
715 VALUE ANALOG INPUT 3
722 VALUE ANALOG INPUT 4
45 VALUE ANALOG OUTPUT 1
731 VALUE ANALOG OUTPUT 2
800 VALUE ANALOG OUTPUT 3
31 VALUE DIGITAL INPUT 1
1273 VALUE DIGITAL INPUT 11
1275 VALUE DIGITAL INPUT 12
1277 VALUE DIGITAL INPUT 13
1279 VALUE DIGITAL INPUT 14
1281 VALUE DIGITAL INPUT 15
34 VALUE DIGITAL INPUT 2
37 VALUE DIGITAL INPUT 3
40 VALUE DIGITAL INPUT 4
43 VALUE DIGITAL INPUT 5
726 VALUE DIGITAL INPUT 6
728 VALUE DIGITAL INPUT 7
52 VALUE DIGITAL OUTPUT 1
1283 VALUE DIGITAL OUTPUT 11
1285 VALUE DIGITAL OUTPUT 12
