2-20 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block Type Range ID Notes
345 FREQUENCY 4 SKIP FREQUENCIES REAL 0.0 to 500.0 Hz 9l
346 OUTPUT SKIP FREQUENCIES REAL _.xx 9m Output
347 INPUT 0 PRESET 1 REAL -32768.00 to 32767.00 9n
348 INPUT 1 PRESET 1 REAL -32768.00 to 32767.00 9o
349 INPUT 2 PRESET 1 REAL -32768.00 to 32767.00 9p
350 INPUT 3 PRESET 1 REAL -32768.00 to 32767.00 9q
351 INPUT 4 PRESET 1 REAL -32768.00 to 32767.00 9r
352 INPUT 5 PRESET 1 REAL -32768.00 to 32767.00 9s
353 INPUT 6 PRESET 1 REAL -32768.00 to 32767.00 9t
354 INPUT 7 PRESET 1 REAL -32768.00 to 32767.00 9u
355 SELECT INPUT PRESET 1 ENUM 0 : INPUT 0
1 : INPUT 1
2 : INPUT 2
3 : INPUT 3
4 : INPUT 4
5 : INPUT 5
6 : INPUT 6
7 : INPUT 7
9v
356 OUTPUT 1 PRESET 1 REAL _.xx 9w Output
357 THRESHOLD ZERO SPEED REAL 0.00 to 300.00 % 9x
359 HYSTERISIS ZERO SPEED REAL 0.00 to 300.00 % 9z
360 AT ZERO SPD DMD ZERO SPEED BOOL FALSE / TRUE a0 Output
362 INPUT Hz SKIP FREQUENCIES REAL _.x a2 Output
363 OUTPUT Hz SKIP FREQUENCIES REAL _.x a3 Output
365 CURRENT LIMIT CURRENT LIMIT REAL 0.00 to 300.00 % a5
371 PARAMETER OPERATOR MENU 2 PREF -1871 to 1871 ab
372 OUTPUT 2 PRESET 1 REAL _.xx ac Output
373 OUTPUT 2 PRESET 2 REAL _.xx ad Output
374 OUTPUT 2 PRESET 3 REAL _.xx ae Output
375 COEFFICIENT A DISPLAY SCALE 2 REAL -32768.0000 to 32767.0000 af 10
376 COEFFICIENT C DISPLAY SCALE 2 REAL -32768.0000 to 32767.0000 ag 10
377 UNITS DISPLAY SCALE 2 STRING max length is 6 chars ah
378 NAME OPERATOR MENU 2 STRING max length is 16 chars ai
379 DECIMAL PLACE DISPLAY SCALE 2 ENUM Same as Tag 334 aj
380 INPUT 0 PRESET 2 REAL -32768.00 to 32767.00 ak
381 INPUT 1 PRESET 2 REAL -32768.00 to 32767.00 al
382 INPUT 2 PRESET 2 REAL -32768.00 to 32767.00 am
383 INPUT 3 PRESET 2 REAL -32768.00 to 32767.00 an
384 INPUT 4 PRESET 2 REAL -32768.00 to 32767.00 ao
385 INPUT 5 PRESET 2 REAL -32768.00 to 32767.00 ap
386 INPUT 6 PRESET 2 REAL -32768.00 to 32767.00 aq
387 INPUT 7 PRESET 2 REAL -32768.00 to 32767.00 ar
388 SELECT INPUT PRESET 2 ENUM Same as Tag 355 as
389 OUTPUT 1 PRESET 2 REAL _.xx at Output
390 INPUT 0 PRESET 3 REAL -32768.00 to 32767.00 au
391 INPUT 1 PRESET 3 REAL -32768.00 to 32767.00 av
392 INPUT 2 PRESET 3 REAL -32768.00 to 32767.00 aw
393 INPUT 3 PRESET 3 REAL -32768.00 to 32767.00 ax
394 INPUT 4 PRESET 3 REAL -32768.00 to 32767.00 ay
395 INPUT 5 PRESET 3 REAL -32768.00 to 32767.00 az
396 INPUT 6 PRESET 3 REAL -32768.00 to 32767.00 b0
397 INPUT 7 PRESET 3 REAL -32768.00 to 32767.00 b1
398 SELECT INPUT PRESET 3 ENUM Same as TAG 355 b2
399 OUTPUT 1 PRESET 3 REAL _.xx b3 Output
400 SOURCE LINK 1 PREF -1871 to 1871 b4 8
401 DESTINATION LINK 1 PREF 0 to 1871 b5 8
402 SOURCE LINK 2 PREF -1871 to 1871 b6 8
403 DESTINATION LINK 2 PREF 0 to 1871 b7 8
404 SOURCE LINK 3 PREF -1871 to 1871 b8 8
405 DESTINATION LINK 3 PREF 0 to 1871 b9 8
406 SOURCE LINK 4 PREF -1871 to 1871 ba 8
407 DESTINATION LINK 4 PREF 0 to 1871 bb 8
408 SOURCE LINK 5 PREF -1871 to 1871 bc 8
409 DESTINATION LINK 5 PREF 0 to 1871 bd 8
410 SOURCE LINK 6 PREF -1871 to 1871 be 8
411 DESTINATION LINK 6 PREF 0 to 1871 bf 8
412 SOURCE LINK 7 PREF -1871 to 1871 bg 8
