Parker 690+ series - Page 199

Parameter Specification 2-55
690+ Series Frequency Inverter
FRAME H - 400V Build Power Dependent Defaults
Quadratic Torque
Parameter Function Block Tag 250kW 250W 300kW 315kW
ACCEL TIME REFERENCE RAMP 258 50.0 50.0 50.0 50.0
AUTO BOOST FLUXING 108 0.00 0.00 0.00 0.00
BASE FREQUENCY MOTOR DATA 1159 50.0 50.0 50.0 50.0
CONTROL MODE MOTOR DATA 1157 VOLTS / HZ VOLTS / HZ VOLTS / HZ VOLTS / HZ
DECEL TIME REFERENCE RAMP 259 50.0 50.0 50.0 50.0
DEFLUX DELAY PATTERN GEN 100 5.0 5.0 5.0 5.0
ENCODER INVERT FEEDBACKS 567 FALSE FALSE FALSE FALSE
ENCODER LINES FEEDBACKS 566 2048 2048 2048 2048
ENCODER SUPPLY FEEDBACKS 761 10.0 10.0 10.0 10.0
FIXED BOOST FLUXING 107 0.00 0.00 0.00 0.00
INJ BASE VOLTS INJ BRAKING 739 50.0 50.0 50.0 50.0
INJ DC LEVEL INJ BRAKING 581 1.00 1.00 1.00 1.00
INJ DC PULSE INJ BRAKING 579 3.0 3.0 3.0 3.0
INJ DEFLUX TIME INJ BRAKING 710 2.0 2.0 2.0 2.0
INJ FINAL DC INJ BRAKING 580 5.0 5.0 5.0 5.0
INJ FREQUENCY INJ BRAKING 577 4.0 4.0 4.0 4.0
LEAKAGE INDUC MOTOR DATA 120 1.49 1.32 1.20 1.08
MAG CURRENT MOTOR DATA 65 99.00 111.30 122.10 136.50
MAX SPEED SETPOINT SCALE 1032 1500 1500 1500 1500
MOTOR CONNECTION MOTOR DATA 124 STAR STAR STAR STAR
MOTOR CURRENT MOTOR DATA 64 330.00 371.00 407.00 445.00
MOTOR POLES MOTOR DATA 84 4 4 4 4
MOTOR VOLTAGE MOTOR DATA 1160 400.0 400.0 400.0 400.0
MOTOR VOLTS VOLTAGE CONTROL 122 400.0 400.0 400.0 400.0
MOTORING LIMIT SLIP COMP 85 150.0 150.0 150.0 150.0
MUTUAL INDUC MOTOR DATA 121 5.94 5.28 4.82 4.31
NAMEPLATE RPM MOTOR DATA 83 1485 1485 1485 1485
OVERLOAD MOTOR DATA 1164 2.2 2.2 2.2 2.2
POWER MOTOR DATA 1158 200.0 220.0 250.0 280.0
POWER FACTOR MOTOR DATA 242 0.88 0.88 0.89 0.89
QUADRATIC TORQUE FEEDBACKS 50 FALSE FALSE FALSE FALSE
REFLUX TIME FLYCATCHING 709 6.0 6.0 6.0 6.0
REGEN LIMIT SLIP COMP 86 150.0 150.0 150.0 150.0
ROTOR TIME CONST MOTOR DATA 1163 1012.16 1012.16 1012.16 1012.16
SEARCH BOOST FLYCATCHING 32 10.0 10.0 10.0 10.0
SEARCH TIME FLYCATCHING 574 15.0 15.0 15.0 15.0
SEARCH VOLTS FLYCATCHING 573 8.0 8.0 8.0 8.0
SPEED INT TIME SPEED LOOP 1188 100 100 100 100
SPEED PROP GAIN SPEED LOOP 1187 20.00 20.00 20.00 20.00
STATOR RES MOTOR DATA 119 0.0233 0.0207 0.0189 0.0169
SYMMETRIC TIME REFERENCE RAMP 267 50.0 50.0 50.0 50.0
TRIP THRESHOLD PWR LOSS CNTRL 1266 447 447 447 447
VHZ BASE FREQ FLUXING 106 50.0 50.0 50.0 50.0
