AXC 1050 (XC)
146
PHOENIX CONTACT 8482_en_03
PROFINET
Type PROFINET controller/device
Number of supported devices Max. 16 (on the PROFINET controller)
Specification 2.3
Conformance class A
Performance class RT
Update rate
16 devices
8 devices
4 devices
2 devices
1 device
32 ms
32 ms
16 ms
8 ms
4 ms
Number of slots 1
Vendor ID 00B0
hex
/176
dec
Device ID 0093
hex
/122
dec
Network interface
Type 2 x Ethernet; 10Base-T and 100Base-T(X)
Transmission speed 10 Mbps (10BASE-T), 100 Mbps (100BASE-T(X))
half duplex, full duplex, auto negotiation
Connection technology CAT5 twisted pair cable
Twisted pair cable with a conductor cross section of 0.14 mm
2
to 0.22 mm
2
8-pos. RJ45 socket
This speed cannot be set manually. It is set automatically by means of auto negotiation.
USB interface
Connection technology Micro-USB type B
Interface type COM port emulation
Transmission rate max. 115.2 kbps
Diagnostics and status indicators
IEC 61131 runtime system (PLC) RUN, FAIL, DBG
Ethernet (ETH) LINK, ACT
Axioline F diagnostics D, E
Supply voltages UL
PROFINET BF, SF
IEC-61131 runtime system
Programming system PC Worx/PC Worx Express
CPU (Central Processing Unit) Nios
®
II (softcore processor), 100 MHz
Shortest cycle time (for cyclic task) 1 ms
Program memory 1 MB, 86 K instructions (IL)
Mass storage 2 MB
