Phoenix Contact AXC 1050 User Manual

AXC 1050 (XC)
26
PHOENIX CONTACT 8482_de_03
BF Red
Status of
PROFINET com-
munication/com-
munication errors
AXC 1050 (XC) concurrently operates as a PROFINET controller and
device
Off
The AXC 1050 (XC) (PROFINET controller) has established an
active communication connection to each configured
PROFINET device and a PROFINET controller has established
an active communication connection to the AXC 1050 (XC)
(PROFINET device).
On
No link status at the Ethernet interfaces and/or no 100-Mbit
transmission and/or no full-duplex operation.
Flashing
(1 Hz)
Link status present, at least one configured PROFINET device
has no communication connection
or
the PROFINET controller has no communication connection.
SF Red
Group error
(PROFINET)
Off PROFINET diagnostics not present.
On PROFINET diagnostics present.
PLC: controller diagnostics
RUN Green
RUN status of the
controller
Off IEC 61131 runtime system not ready to operate.
Flashing
(0.5 Hz)
IEC 61131 runtime system successfully initialized.
Control function is in the READY/STOP state, program not pro-
cessed.
Flashing
(2 Hz)
Controller reset to default state (see Section "Reset button
(concealed)" on page 30).
On
IEC 61131 runtime system successfully initialized and a pro-
gram is running.
Control function is in the RUN state.
FAIL Red Failure
On
A runtime error has occurred in the IEC 61131 runtime system
program.
Off
No runtime error has occurred in the IEC 61131 runtime system
program.
Flashing
(0.5 Hz)
The hardware watchdog of the controller has been triggered.
DBG Yellow
Debug mode
(troubleshooting)
On
The IEC 61131 runtime system/controller is in debug mode, i.e.,
debug mode has been activated in PC Worx (breakpoint(s) set
and/or variable(s) forced).
The state of the RUN LED is not affected.
Flashing
(2 Hz)
Boot phase of the controller (from sending the BootP request to
assigning the IP address settings) if the MAC address of the
controller has been entered in the PC Worx software. Other-
wise, flashing stops after three failed boot requests.
Table 3-1 Diagnostics and status indicators of the controller
Desig-
nation
Color Meaning State Description
