Piper Dakota - Maximum Distance between Supports for Fluid Tubing

CHART 2001. THREAD LUBRICANTS
CHART 2002. MAXIMUM DISTANCE BETWEEN SUPPORTS FOR FLUID TUBING
20 - 10 - 00
Page - 20 - 07
Reissued: August 1, 1986
1E10
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
TYPE OF LINE TYPE OF LUBRICANT
—CAUTION—
Lubricate engine fittings only with the fluid contained in the
particular lines.
Brakes MIL-H-5606
Deicer (Air) TT-A-580 (JAN-A-669), Anti-Seize Compound
(White Lead Base)
Freon TT-A-580 or MIL-T-5544, Anti-Seize Compound
Fuel MIL-T-5544, Anti-Seize, Graphite Petrolatum
Oil MIL-G-6032, Lubricating Grease
(Gasoline and Oil Resistant)
Oxygen Ribbon Dope Thread Sealant
Permacel 412
Pitot and Static TT-A-580 (JAN-A-669), Anti-Seize Compound
(White Lead Base)
TUBE OD DISTANCE BETWEEN SUPPORTS (IN.)
(IN.) ALUMINUM ALLOY STEEL
1/8 9-1/2 11-1/2
3/16 12 14
1/4 13-1/2 16
5/16 16-1/2 20
1/2 19 23
5/8 22 25-1/2
3/4 24 27-1/2
1 26-1/2 30
