Piper Dakota - Alternate Turn and Bank; Turn and Bank

Figure 9l-13. Alternate Turn and Bank Figure 91-14. Alternate Turn and Bank
(Early Models) (Later Models)
THIS SPACE INTENTIONALLY
LEFT BLANK
Figure 9l-l5. Turn and Bank
91 - 33 - 00
Page 91 - 29
Reissued: August 1, 1986
3C2
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
