77 - 23 - 00
Page 77 - 06
Reissued: August 1, 1986
2K9
CHART 7706. TROUBLESHOOTING (CYLINDER HEAD TEMPERATURE GAUGE)
Instrument shows no indi- Power supply wire broken. Repair wire.
cation.
Defective instrument. Replace instrument.
Master switch off.
Instrument goes all the Wire broken between Repair wire.
way to upper stop. sender and gauge.
Defective sender. Replace sender.
—END—
TROUBLE CAUSE REMEDY
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
