Piper Dakota - Air Conditioning Condenser

COMPONENT LUBRICANT FREQUENCY
1. CONDENSER HINGE AND ACTUATORS MIL-L-7870 100 HRS
2. CONDENSER DOOR ACTUATING TRANSMISSION MIL-G-23827 500 HRS
SPECIAL INSTRUCTIONS
Transmission to be 1/2 full of grease. Apply grease during sssembly and lubricate transmission ball nut and screw
with MIL-G-23827 grease.
Figure l2-9. Lubrication Chart (Air Conditioning Condenser)
12 - 27 - 00
Page -12 - 26
Reissued: August 1, 1986
1D22
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
