BAGGAGE DOOR
REMOVAL OF BAGGAGE DOOR
With door open, remove hinge pin from hinge and remove door.
INSTALLATION OF BAGGAGE DOOR
Place door in position so that hinge halves are properly matched and install hinge pin.
—NOTE—
It will not be necessary to replace the hinge pin with a new pin if
it is free of bends and wear.
BAGGAGE DOOR LOCK ASSEMBLY
REMOVAL OF BAGGAGE DOOR LOCK ASSEMBLY
1. With door open, remove nut from back of lock assembly using a special wrench. (This tool may be
fabricated from dimensions in chapter 91.)
2. Remove lock assembly through front of door.
INSTALLATION OF BAGGAGE DOOR LOCK ASSEMBLY
1. Place lock into position for installation.
2. Install nut on lock assembly and tighten using special wrench. (Refer to chapter 91.)
BAGGAGE DOOR HINGE
REMOVAL OF BAGGAGE DOOR HINGE
1. Remove door from airplane as described in Removal of Baggage Door.
2. Remove hinge half from airplane or door by drilling out rivets and removing hinge.
INSTALLATION OF BAGGAGE DOOR HINGE
1. Place hinge halves together and install hinge pin.
2. Install door into the closed position. Drill two end rivet holes and install rivets.
3. Operate door and check for proper fit and installation. Drill remaining holes and install rivets.
—END—
2F20
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
52 - 33 - 00
Page 52-06
Reissued: August 1, 1986
