STARTING MOTOR SERVICE TEST SPECIFICATION
Prestolite specifications for 12-volt starting motors installed as standard equipment on this airplane are as
follows:
CHART 8002. STARTING MOTOR SPECIFICATIONS
EXTERNAL POWER RECEPTACLE
When using a 12-volt battery for external power starting and airplanes battery is nearly depleted, proceed
as follows:
1. Disconnect airplanes battery at negative terminal to prevent excessive Loading of external starting
battery.
2. Check that all airplane’s electrical equipment is OFF.
3. Connect external battery to external power receptacle; turn master switch ON and start engine using
normal starting procedure.
4. Turn master switch OFF; remove external battery, and reconnect battery at negative terminal.
5. Turn master switch ON.
—END—
80 - 13 - 00
Page 80 - 10
Reissued: August 1, 1986
2L6
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
Motor Model MZ4222
Min. Brush Tension 32 oz.
Max. Brush Tension 40 oz.
No Load Test (75
0
F)
Volt 10
Max. Amps 75
Min. R.P.M. 1600
Stall Torque
Amps Max. 560
Min. Torque, Ft. Lbs. 37.5
Approx. volts 4.0
