CHART 601. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS (CONT)
FUEL SYSTEM CAPACITY
Left wing tank 38.5 gal.
Right wing tank 38.5 gal.
Total 77 gal.
Total unusable 5 gal.
LANDING GEAR
Type Fixed
Shock strut type Combination air-oil
Wheel tread 10.0 Ft.
Wheel base 6 Ft. 6.06 Inches
Turning radius, nose wheel l3 Ft.
Nose wheel travel 30° +/- l° left & right
Wheel, nose McCauley D30665 or Cleveland
40-56, 6:00x6
Wheel, main Cleveland 40-86B, 6:00 x 6
Wheel, main, heavy duty Cleveland 40-90A, 6:00 x 6
Brake type, standard Cleveland 30-55, single disc,
single piston
Brake type, heavy duty Cleveland 30-65, single disc,
double piston
Tires, nose 6:00 x 6, 6 ply rating
Tires, main 6:00 x 6, 6 ply rating
Tires, main, heavy duty 6:00 x 6, 8 ply rating
Tire pressure, nose 28-30 psi
Tire pressure, main 35-40 psi
Tire pressure, main, heavy duty 35-40 psi
6 - 10 - 00
Page - 6 - 02
Reissued: August 1, 1986
