PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 6
Nov 30/06
3I6
34-50-00
DISPLAY MODE . . . . . . . . . . . . . . AUTO
LEVEL . . . . . . . . . . . . . . . . . . . . . . . . 75
BKLT . . . . . . . . . . . . . . . . . . . . . . . AUTO
LVL . . . . . . . . . . . . . . . . . Not Selectable
RSP TIME. . . . . . . . . . . . . . . . . . . . . . . 4
MIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
BKLT SRCE . . . . . . . . . . . . . . . . PHOTO
SLOPE . . . . . . . . . . . . . . . . . . . . . . . . 50
OFFSET . . . . . . . . . . . . . . . . . . . . . . . 50
KEY. . . . . . . . . . . . . . . . . . . . . . . . AUTO
LVL . . . . . . . . . . . . . . . . . Not Selectable
RSP TIME. . . . . . . . . . . . . . . . . . . . . . . 4
MIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
KEY SRCE . . . . . . . . . . . . . . . . . . . . 28V
SLOPE . . . . . . . . . . . . . . . . . . . . . . . . 20
OFFSET . . . . . . . . . . . . . . . . . . . . . . . 30
CONTRAST MODE . . . . . . . . . . . AUTO
CHART 3
DISPLAY MODE AND KEY LIGHTING
Function Selection Description
CHART 2
VOICE AND VOLUME
VOLUME MAX
VOICE MALE
MESSAGE (0-5) Selected Audio Tones and Messages
0 = Toggle a continuous tone on and off
1 = Attention Tone, precedes voice messages to
attract the pilot’s attention.
2 = “Leaving Altitude,” when altitude monitor is
active and the altitude deviation is exceeded.
3 = “Traffic,” when a TIS traffic alert is received.
4 = “Time Expired,” when the countdown expires.
5 = “Traffic Not Available,” when TIS service is not
available or out or range of an operating TIS
MODE S site.
6-9 are not used.
ALTITUDE MONITOR OFF When Altitude Pre-Select is installed.
TONE When Altitude Pre-Select is not installed.
PAGE CHANGE ENABLE
COUNTDOWN TIMER TONE
