PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 7
Nov 30/06
3I7
34-50-00
RS-232 CONFIG GTX
232 INPUT INPUT OUTPUT
CHANNEL 1 OFF OFF
CHANNEL 2 OFF OFF
CHART 5
RS-232 INPUT AND OUTPUT
GTX 330
429 INPUT SPEED DATA
CHANNEL 1 HIGH GPS/FMS
CHANNEL 2 HIGH OFF
CHANNEL 3 LOW OFF
CHANNEL 4 OFF
429 OUTPUT DATA
CHANNEL 1 OFF
CHANNEL 2 GARMIN W/TIS
GARMIN W/SKYWATCH
CHART 4
ARINC 429 CONFIGURATION PAGE
CHART 6
OPERATION CONFIGURATION
VS RATE . . . . . . . . . . . . . . . . . . . . . . . . . 500
FORMAT . . . . . . . . . . . . . . . . . . . . . . . . FEET
VFR ID . . . . . . . . . . . . . . . . . . . . . . . . . . 1200
ALTITUDE ALERT DEVIATION . . . . . . . . 200
SQUAT SWITCH . . . . . . . . . . . . . . . . . . “NO”
“SENSE” . . . . . . . . . . . . . . . . . . . . . . . . . . “--”
DELAY TIME . . . . . . . . . . . . . . . . . . . . . . . 24
AUTO FLIGHT TIMER. . . . . . . . . . . MANUAL
Binary Hexadecimal Decimal Binary Hexadecimal Decimal
CHART 7
HEXADECIMAL CONVERSION
/0000 0 0 /1000 8 8
/0001 1 1 /1001 9 9
/0010 2 2 /1010 A 10
/0011 3 3 /1011 B 11
/0100 4 4 /1100 C 12
/0101 5 5 /1101 D 13
/0110 6 6 /1110 E 14
/0111 7 7 /1111 F 15
To Next Page
