PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 8
Nov 30/06
3I8
34-50-00
2 Non-US Registered Aircraft
a For entering Non-U.S. Aircraft Registration, press the CRSR key one time, then
8 or 9 to select ADDRESS HEX.
b Non-U.S. Aircraft Registry normally supplies a 24 bit binary code, known as the
ICAO Aircraft Code for the Mode S address in lieu of directly entering the N# for
U.S. registered aircraft.
c The GTX 330 only accepts a hexadecimal format for the Non-U.S. Registered
Aircraft, so the 24 bit binary code must be converted to a hexadecimal format.
d Convert the 24 bit binary code to hexadecimal as follows:
1) 24 bit binary code: 11100100011111101101101
2) Separate for hex conversion: 1110/0100/0111/1110/1110/1101
3) Apply the hexadecimal values found in Chart 7.
E47EED
1110/ 0100/ 0111/ 1110/ 1110/ 1101
e Enter the hexadecimal address using the number keys. Press the CRSR key to
select the numeric entry field. Press a key repeatedly to scroll through the
digit/alpha characters for that entry field.
f Repeat step 5 until the complete number is entered.
g
for FLIGHT ID select “CONFIG ENTRY” and enter the Hex code or select
“POWER UP ENTRY”.
h When finished, press the CRSR key to accept the number entry.
3
On the “MODE S Aircraft Type” Page, select “<15.5k Lb” for AC TYPE, and “<=300 kt”
for MAX AIRSPEED.
4 When entries are complete, cycle unit power and check for entries.
