All-New Event Presentation Switching Solutions
User Manual
8 U5/U5 Pro Event Controllers
www.pixelhue.com
175
1. 2x USB 3.0
5. 2x HDMI 2.0+1x HDMI 1.3 connectors
2. Gooseneck lamp connector
6. USB (type-B)
3. Timecode module connector
7. 4x USB 2.0 ports
4. 2x ETHERNET ports
8. 2x Power modules
Connector Description
No.
Area
Connector
Qty
Function
1
USB
USB 3.0
2
2x USB 3.0 on the right side of U5
Connect to the mouse, keyboard,
USB drive, etc.
2
Gooseneck lamp
connector
-
1
or
2
Connect the gooseneck lamp.
The U5 has one gooseneck lamp
connector and the U5 Pro has two.
3
Timecode
module
LTC
3-pin XLR
connector
3
1x LTC IN, 2x LTC OUT

Connect to the external LTC-
format timecode input device.

LTC timecode output
MTC
5-pin XLR
connector
3
1x MTC IN, 1x MTC OUT, 1x USB
(type-B)

MTC IN: Connect to the external
MTC-format timecode input
device.

MTC OUT: MTC timecode output

USB DEVICE: Support input and
output of MTC timecodes from
USB MIDI device
4
ETHERNET
Neutrik
Ethernet ports
2
2x Neutrik Gigabit Ethernet ports

Connect to the Ethernet control
port of the backend control
device.

Support mutual backup mode.
The two Ethernet ports use the
same IP address.

Support independent mode. The
two Ethernet ports use two IP
addresses.

Support transmission of the
input view information.
5
MULTIVIEWER
HDMI 2.0
2

Generally connect to the MVR
connector of the seamless
switcher to view the output
