All-New Event Presentation Switching Solutions
User Manual
LED Work Lights and Switches
At some event venues, the lights may be very dim. For users’ convenience, the
P20 is designed with two LED work lights to provide adequate light for rear panel
operations. The LED work lights come with pushbutton switches (red) next to
them.
Specifications of input and output video connections
DP 1.2
− Maximum resolution: 4096×2160@60Hz/8192×1080@60Hz
− Minimum resolution: 800×600@60Hz
− Maximum width: 8192 pixels (8192×1080@60Hz)
− Maximum height: 8192 pixels (1080×8192@60Hz)
− Maximum frame rate: 120 Hz
− EDID management (support for standard resolutions and custom resolutions)
− HDCP 1.3 compliant
HDMI 2.0
− Maximum resolution: 4096×2160@60Hz/8192×1080@60Hz
− Minimum resolution: 800×600@60Hz
− Maximum width: 8192 pixels (8192×1080@60Hz)
− Maximum height: 8192 pixels (1080×8192@60Hz)
− Maximum frame rate: 120 Hz
− Support for HDR
− EDID management (support for standard resolutions and custom resolutions)
− HDCP 2.2 compliant and downward compatible
12G-SDI
− Support for ST-2082 (12G), ST-2081 (6G), ST-424 (3G), ST-292 (HD)
− Maximum resolution: 4096×2160@60Hz
− Maximum frame rate: 60 Hz
− Support for interlaced input signal
P10 Hardware Introduction
5.2.1 Front Panel
The P10 front panel is designed with a 5-inch LCD, a knob and a variety of function
buttons that allow for menu operations by button presses. A USB port is provided on
the front panel for updating device firmware, import and export files.
