P20/P10 Menu Operations
The 5-inch LCD and a variety of buttons on the front panel of the P20/P10 allow for
pretty darn simple operations. The following sections will introduce the operations in
detail.
6.1.1 Startup and Shutdown
Connect all the necessary cables and power cords properly, locate and turn on the
rocker switch on the rear panel. The startup screen appears, as shown in Figure 6-1.
The P20/P10 front panel provides a 5-inch LCD screen allowing for more intuitive
operations.
Startup screen
To turn off the P20/P10, press the power button on the front panel and select OK
from the dialog box displayed on the LCD screen.
6.1.2 Home Screen
After the startup, the home screen is displayed. The following descriptions use the
P20 home screen as an example, as show in Figure 6-2 and Table 6-1.
