All-New Event Presentation Switching Solutions
User Manual
Solution Overview
The event presentation switching solutions include two parts basically: event
presentation switchers and event controllers/PixelFlow (PC). The solutions are
specifically designed for easy management of multi-display for small/medium/large-
sized events or visual management systems.
P20+U5/U5 Pro+PixelFlow
The P20 can work with the U5 or U5 Pro event controller. The following takes the U5
as an example for illustration.
Switcher mode (P20+U5+PixelFlow)
When the output capacity is 4K, two output connectors work as primary and the other
six work as backup. When the output capacity is DL, four output connectors work as
primary and the other four work as backup.
PGM only mode (P20+U5+PixelFlow)
When the output capacity is 4K, four output connectors work as primary and the
other four work as backup. When the output capacity is DL, four output connectors
work as primary and the other four work as backup.
