PIXELHUE P20 - Device Operations; Basic Operations; Startup and Shutdown

All-New Event Presentation Switching Solutions
User Manual
8 U5/U5 Pro Event Controllers
www.pixelhue.com
176
monitoring.

Up to 4K×2K@60Hz
HDMI
HDMI 1.3
1

Generally connect to the output
connector of the media server to
display its user interface.

Up to 2K×1K@60Hz
6
USB
USB 2.0
4
Connect to the mouse, keyboard,
USB drive, etc.
7
MIDI / KVM
USB (type-B)
1

KVM: Connect to a PC or media
server via USB cable for KVM
control.

MIDI: Connect to the MIDI control
device for MIDI command
output.

KVM and MIDI can be turned on
at the same time.
8
Power module
-
-
1
or
2

Power connector specifications:
100-240V~, 6A, 50/60Hz

The U5 has one power module.

The U5 Pro has two power
modules, one primary and one
backup.
Device Operations
8.3.1 Basic Operations
 Press: Press the button and release it within 3 seconds.
 Hold down: Press and hold the button for 3 seconds or longer.
 Click/Tap: Click or tap the menu once on the screen.
 Double click/tap: Click or tap the same area twice quickly.
 Combination of buttons: Hold down or to activate combination
function and then press another function button to trigger the corresponding
function.
 Pinch in or stretch out: Place two fingers on the touchscreen and pinch in or
stretch out. This operation is only to zoom in or out pictures on the smart
touchscreen.
8.3.2 Startup and Shutdown
Prerequisites
A power supply is connected and the power is supplied normally.
