PIXELHUE P20 - U5;U5 Pro

All-New Event Presentation Switching Solutions
User Manual
B Supported Resolutions
www.pixelhue.com
203
B.2 Q8
Input
Bit Depth
Sampling
Supported Resolutions
Supported Bandwidth
DP 1.2
8bit
RGB 4:4:4
8192×1080@60Hz
4096×2160@30Hz
3840×2160@60Hz
21.6 Gbps
YCbCr 4:4:4
YCbCr 4:2:2
10bit
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2
12bit
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2
HDMI 2.0
8bit
RGB 4:4:4
4096×2160@60Hz
8192×1080@60Hz
18 Gbps
YCbCr 4:4:4
YCbCr 4:2:2
10bit
RGB 4:4:4
4096×2160@30Hz
4096×1080@60Hz
YCbCr 4:4:4
YCbCr 4:2:2
4096×2160@60Hz
12bit
RGB 4:4:4
4096×2160@30Hz
4096×1080@60Hz
YCbCr 4:4:4
YCbCr 4:2:2
4096×2160@60Hz
12G-SDI
8bit
YCbCr 4:2:2
4096×2160@60Hz
11.88 Gbps
10bit
YCbCr 4:2:2
12bit
YCbCr 4:2:2
B.3 U5/U5 Pro
Input
Bit Depth
Sampling
Supported Resolutions
Supported Bandwidth
HDMI 2.0
8bit
RGB 4:4:4
4096×2160@60Hz
8192×1080@60Hz
18 Gbps
YCbCr 4:4:4
YCbCr 4:2:2
10bit
RGB 4:4:4
4096×2160@30Hz
4096×1080@60Hz
YCbCr 4:4:4
YCbCr 4:2:2
4096×2160@60Hz
12bit
RGB 4:4:4
4096×2160@30Hz
