InfoFrame override (P20)
Description
Menu Item
Description
Color/Sample
Set the input color space and sampling rate
Bit Depth
Set the input bit depth
Bit depth refers to the color information stored in an image. The higher
the bit depth of an image, the more colors it can store.
Quantization
Range
Set the input quantization range
Dynamic
Range
Convert the dynamic range. Free conversion between SDR, HDR10 and
HLG is supported.
This menu item is displayed only when Dynamic Range Conversion is
turned on ( ).
Color Gamut
Set the input color gamut standard
This menu item is displayed only when Dynamic Range Conversion is
turned on ( ).
Tone Mapping
Set mapping mode. This menu item is displayed when Dynamic Range
is HDR10.

: On. Luminance overrides Peak Screen Brightness.

: Off. Luminance overrides Max CLL.
Luminance
Peak luminance. This menu item is displayed when Dynamic Range is
HDR10 or HLG.
Ambient
Brightness
Ambient brightness. This menu item is displayed when Dynamic
Range is HDR10 or HLG.
When you set a parameter value to AUTO, the device will get the actual value from
the properties of the input source automatically.
