User’s Manual of GS-5220 LCD Series
205
• Frame Type
Shows whether the port accepts all frames or only tagged frames. This
parameter affects VLAN ingress processing. If the port only accepts
tagged frames, untagged frames received on that port are discarded.
• Port VLAN ID
Shows the PVID setting for the port.
• Tx Tag
Shows egress filtering frame status whether tagged or untagged.
• Untagged VLAN ID
Shows UVID (untagged VLAN ID). Port's UVID determines the packet's
behavior at the egress side.
• Conflicts
Shows status of Conflicts whether exists or Not. When a Volatile VLAN
User requests to set VLAN membership or VLAN port configuration, the
following conflicts can occur:
Functional Conflicts between feature.
Conflicts due to hardware limitation.
Direct conflict between user modules.
Buttons
: Select VLAN Users from this drop down list.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3
seconds.
: Click to refresh the page immediately.
