- 142 -
F
IGURE
5-1
19
2.
To change the IGMP setting, highlight
IGMP
and press Enter. When the following screen appears,
highlight the desired setting and press
Enter.
F
IGURE
5-120
3.
When you finish, press the Esc key
until you return to the desi
r
ed screen.
Note:
To understand the
IGMP options Passive Mode and Active Mode, refer to
Section 5.3
“IP
Multicast Group Perspective”.
149
151
