- 252 -
F
IGURE
7-50
O
THER
P
ROTOCOLS
W
INDOW
1. For
GVRP
, enable or disable it.
2. For
IGMP
, disable it or make it passive or active.
3. Click
the
Update Setting
button.
7.1
1 Port T
runking
To associate ports to a trunk group, point to Adv
anced Setup and click Port
Trunki
ng. A list of
trunk
groups and associated po
rts similar to the following appear.
259
