- 143 -
5.13 Port T
runking
Using
Port T
runking
from the Advanced Management scree
n
,
you can associate ports with trunk
groups.
1. From
the
Advanced Management
scree
n, highlight
Port T
runking
and press the
Enter
key
. Y
ou will
receive a screen as shown in Figure 5-107.
F
IGURE
5-121
P
ORT
T
RUNKING
2.
Highlighting the trunk group to which
you want to ports assig
ned, then press
Enter
.
Note
: T
runk 27, 28 29 is base on WGSW-2402A. For WGSW-404, it will start from 9 to 12.
