- 146 -
5.14 Port Mirroring
Using
Port Mirroring
from the Advanced
Management screen, you can mirror one port to another.
Note:
Only WGSW-2402A supports this
function.
1.
From the Advanced M
anagement screen, highlight
Port Mirroring
and press the Enter key. The
screen in
Figure 5-126
ap
pears.
F
IGURE
5-126 P
ORT
M
IRRORING
S
CREEN
2.
Highlight the port you want to mirror to, and t
hen press Enter. The Port Mirrorin
g Options screen
appears.
153
155
