Planet WGSW-404 User Manual

- 178 -
2. Perform one of the following steps:
 To specify a megabit profile that is used by a 10/100 Megabit port, refer to Section 5.15.5.1
“Megabit Profile”.
 To specify a gigabit profile that is used by a Gigabit port, refer to Section 5.15.5.2 “Gigabit
Profiles”.
5.15.2.5.1 Megabit Profile
To select a megabit profile:
1. With Megabit Profile highlighted in the QoS Profile screen, press the Enter key. The Megabit
Profile screen appears.
F
IGURE
5-162
2. Use the Down Arrow key to highlight a profile, then press the Enter key. The Megabit Profile
Attributes screen appears.
Note:
In the Megabit Profile screen:
A1 = active profile #1, which can be used by any 10/100 Megabit port.
A2 = active profile #2, which can be used by any 10/100 Megabit port.
A3 = active profile #3, which can be used by any 10/100 Megabit port.
A4 = active profile #4, which can be used by any 10/100 Megabit port.
NA = indicates a profile that is not active and cannot be used by any 10/100 Megabit port.
