- 21 -
 To log out, highlight Logout and press Enter.
 To save the current settings and remain in the configuration program, highlight Save Settings,
press Enter.
 To restore the factory default settings, highlight Restore Default Settings and press Enter.
 To reboot, highlight Reboot and press Enter.
4.2 Navigating Through the Console Interface
The console interface consists of a series of menu boxes. Each menu box has several options, which
are listed vertically. A highlight in each box lets you select the option you wish to choose; pressing the
Enter key activates the highlighted option. Table 4-1 shows the keys used for navigating through the
console interface.
T
ABLE
4-1 N
AVIGATING
T
HROUGH THE
C
ONSOLE
I
NTERFACE
To... Press This Key...
Move the highlight one line up in a menu box. Up arrow or K
Move the highlight one line down in a menu box. Down arrow or J
Move the highlight between screens. Tab
Select the highlighted option. Enter
Move to the previous menu. Escape
4.3 Performing Basic Management Activities
Basic management activities consist of General, LAN port, and console port tasks. To perform basic
management activities:
1. From the Switch Management screen (see Figure 4-1), highlight Basic Management and press
Enter. The Basic Management screen in Figure 4-2 appears.
