7. Secure the cable to the floor retainers
o
.
8. Install the shift cable into the dash retainer, and
torque the locknut
i
to specification.
TORQUE
Shift Cable Locknut:
13 ft-lbs (18 Nm)
9. Install the shift cable
u
into the shift lever assembly
and secure with a new fastening nut
y
. Torque to
specification.
TORQUE
Shift Cable Fastening Nut:
13 ft-lbs (18 Nm)
10.Install the left dash bracket
t
by rotating in as
shown.
