5. install the door trim panel and engage the retainers
r
. Install and torque the fastener
e
to specification.
TORQUE
Door Panel Trim Fastener:
42 in-lbs (5 Nm)
6. Install the crank handle and u-clip to secure the crank
handle
w
to the door.
7. Install the door handle and fasteners
q
to secure the
door handle to the door assembly. Torque to
specification.
TORQUE
Door Handle Fastener:
42 in-lbs (5 Nm)
BODY / FRAME
