9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
1.17
CHAPTER 10 — BODY / FRAME
PART DESCRIPTION
TORQUE
SPECIFICATION
AC Suction Hose 18 ft-lbs (24 Nm)
AC Pressure Hose 18 ft-lbs (24 Nm)
HVAC Unit Mounting
Bracket Fastener
6 ft-lbs (8 Nm)
Air Distributor Manifold
Fastener
18 in-lbs (2 Nm)
Filter Support Fastener 18 in-lbs (2 Nm)
Air Filter Band Clamp 24 in-lbs (3 Nm)
Upper Glovebox Mounting
Fastener
10 in-lbs (1 Nm)
Rear Close Off Panel
Fastener
42 in-lbs (5 Nm)
Side Net Fastener 6 ft-lbs (8 Nm)
Overhead Light Fastener 18 in lbs (2 Nm)
Roof Fastener 42 in lbs (5 Nm)
1/4 Turn Glovebox Latch 36 in lbs (4 Nm)
CHAPTER 11 — ELECTRICAL
PART DESCRIPTION
TORQUE
SPECIFICATION
ECU Retaining Fastener
24 in lbs (2.7 Nm)
Battery Box Fastener 3.5 ft-lbs (5 Nm)
Battery Bracket Fastener
3.5 ft-lbs (5 Nm)
Starter Cable Wiring Nuts 48 in-lbs (5 Nm)
Spark Plug 9 ft–lbs (12 Nm)
Brake Switch
15 ft-lbs (20 Nm)
CPS Retaining Fastener 9 ft-lbs (12 Nm)
ETC Housing Retaining
Fastener
5 ft-lbs (7 Nm)
Oxygen Sensor 18 ft-lbs (24 Nm)
T-MAP Retaining
Fastener
3 ft-lbs (4.5 Nm)
ECT Sensor
16 ft-lbs (22 Nm)
Speed Sensor 10 ft-lbs (14 Nm)
Headlight Fastener 5 ft-lbs (7 Nm)
Battery Terminal Fastener 40 in-lbs (5 Nm)
Alternator Hot Wire at
Terminal Block
3.3 ft-lbs (4 Nm)
Terminal Block Fasteners
3 lb-ft (4 Nm)
Ignition Coil Retaining
Bolt
8 lb-ft (11 Nm)
Tail Light Fasteners
4 lb-ft (5 Nm)
Starter Motor Fasteners
7 lb-ft (10 Nm)
GENERAL INFORMATION
