Polaris RANGER XP 1000 2018 User Manual

1.16
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
CHAPTER 10 — BODY / FRAME
PART DESCRIPTION
TORQUE
SPECIFICATION
Cargo Box Bracket
Fastener
5 ft-lbs (7 Nm)
Door Hinge Fastener 17 lb-ft (23 Nm)
Door Retainer Fastener
6 lb-ft (8 Nm)
Rear Glass Fastener
Torque until lock and
ride clamps are fully
seated
Skid Plate Fastener
6 ft-lbs (8 Nm)
Instrument Cluster
Fastener
12 in lbs (1 Nm)
Seat Base Fastener
10 ft-lbs (14 Nm)
Cross Bar Fastener 14 ft-lbs (19 Nm)
Dash Bracket Fastener
6 ft-lbs (8 Nm)
Dash, Storage Fastener 42 in-lbs (5 Nm)
Dash, Upper Storage
Fastener
10 in-lbs (1 Nm)
Dash, Main Fastener
42 in-lbs (5 Nm)
Glovebox Fastener 42 in-lbs (5 Nm)
Fender-Rear, Rocker
Fastener
42 in-lbs (5 Nm)
Seat-Back, Fastener 18 inch-lbs (2 Nm)
Buckle, Seat Mounting
Fastener
40 ft-lbs (54 Nm)
Seat Back Frame
Fastener
10 ft lbs (14 Nm)
Seat-Belt, Fastener 40 ft-lbs (54 Nm)
Seat Bracket Hinge
Fastener
6 ft lbs (9 Nm)
Seat Bracket Pivot
Fastener
10 ft lbs (14 Nm)
Seat Bracket Pivot
Mounting Fastener
10 ft lbs (14 Nm)
Seat, Frame Fastener 18 ft-lbs (24 Nm)
Seat Slide Assembly
Fastener
6 ft lbs (8 Nm)
Seat Shock Ball End
Fastener
7 ft lbs (9 Nm)
Handle, Grab Fastener 10 ft-lbs (14 Nm)
CHAPTER 10 — BODY / FRAME
PART DESCRIPTION
TORQUE
SPECIFICATION
Frame, Cab Fastener 65 ft-lbs (61 Nm)
Weld, Cab Frame
Fastener
40 ft-lbs (49 Nm)
Weld, Seat Bolster
Fastener
10 ft-lbs (14 Nm)
Bolster, Bracket Fastener
6 ft-lbs (8 Nm)
Plate, Windshield Mount
Fastener
36 ft-lbs (49 Nm)
Cargo Box Latch Bushing
Fastener
13 ft lbs (18 Nm)
Cargo Box Fastener 42 in-lbs (5 Nm)
Cargo Box Frame
Fastener
5 ft lbs (7 Nm)
Cargo Box Heat Shield
Fastener M6X1.0
42 in-lbs (5 Nm)
Cargo Box Heat Shield
Fastener 14X5/8
18 in lbs (2 Nm)
Inner Cargo Box Fastener 8 in lbs (1 Nm)
Outer Cargo Box Panel
Fastener
8 in lbs (1 Nm)
Lower Tailgate Support
Fastener
10 ft lbs (14 Nm)
Tailgate Latch Fastener
7 ft lbs (9 Nm)
Tailgate Support Fastener 42 in-lbs (5 Nm)
Tailgate Cap Fastener 22 in lbs (2 Nm)
Outer Tailgate Panel
Fastener
22 in lbs (2 Nm)
Front Bumper Fastener
30 ft-lbs (41 Nm)
Headliner Fastener
24 in-lbs (3 Nm)
Body Fastener
42 in-lbs (5 Nm)
Front Fender Fasteners
22 in lbs (3 Nm)
HVAC Unit Mounting
Fastener
8 ft-lbs (11 Nm)
HVAC Condenser
Fastener
35 in-lbs (4 Nm)
AC Hose Clamp Fastener 6 ft lbs (8 Nm)
AC Hose, Condenser to
Evaporator
12 ft-lbs (16 Nm)
