9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
1.15
CHAPTER 9 — BRAKE SYSTEM
PART DESCRIPTION
TORQUE
SPECIFICATION
Master Cylinder Mounting
Fastener
12 ft-lbs (16 Nm)
Caliper Bleed Screw 4 ft-lbs (5.5 Nm)
Brake Line Banjo Bolt 15 ft-lbs (20 Nm)
Master Cylinder Banjo
Fastener
15 ft-lbs (20 Nm)
Front Caliper Mounting
Fastener
28 ft-lbs (38 Nm)
Rear Caliper Mounting
Fastener
46 ft-lbs (62 Nm)
Pedal Bracket Nuts
8 ft-lbs (11 Nm)
Brake Disc Mounting
Fastener
18 ft-lbs (24 Nm)
