1.14
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
CHAPTER 7 — FINAL DRIVE
PART DESCRIPTION
TORQUE
SPECIFICATION
Front Gearcase Fill /
Drain Plug
10 ft-lbs (14 Nm)
Carrier Fastener
40 ft-lbs (54 Nm)
Rear Prop Shaft (to
transmission) Fastener
22 ft-lbs (30 Nm)
Front Gearcase Cover
Plate Fastener
9 ft-lbs (12 Nm)
Front Gearcase Mounting
Fastener
30 ft-lbs (41 Nm)
CHAPTER 8 — STEERING / SUSPENSION
PART DESCRIPTION
TORQUE
SPECIFICATION
Lower Steering Shaft to
Rack Pinch Fastener
48 ft-lbs (65 Nm)
Power Steering Mount
Fastener
30 ft-lbs (41 Nm)
Power Steering Unit
Frame Fastener
14 ft-lbs (19 Nm)
Upper Steering Shaft
Pinch Fastener
25 ft-lbs (34 Nm)
Lower Steering Shaft
Pinch Fastener
25 ft-lbs (34 Nm)
Steering Wheel Tilt
Assembly Nut
40 ft-lbs (54 Nm)
Steering Adjustment
Shock Assembly Nut
7 ft-lbs (10 Nm)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Steering Rack Mounting
Nuts
40 ft-lbs (54 Nm)
Tie Rod Jam Nut
13 ft-lbs (18 Nm)
Tie Rod Retaining Nut
30 ft-lbs (41 Nm) + 90°
Shock Mounting Fastener
40 ft-lbs (54 Nm)
Stabilizer Bar Link Nut
40 ft-lbs (54 Nm)
Upper A-Arm Fastener
40 ft-lbs (54 Nm)
Lower A-Arm Fastener
40 ft-lbs (54 Nm)
Ball Joint Nut
45 ft-lbs (61 Nm)
Stabilizer Bar Mount
Fastener
31 ft-lbs (42 Nm)
Stabilizer Bar Link
Fastener
17 ft-lbs (23 Nm)
