9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
1.13
CHAPTER 5 — PVT SYSTEM
PART DESCRIPTION
TORQUE
SPECIFICATION
PVT Inner Cover
Fastener
37 ft-lbs (50 Nm)
STEP 1: Torque to
37 ft-lb (50 Nm)
STEP 2: Loosely
install bolts by
hand
STEP 3: Loosely
install bolts by
hand
STEP 4: Loosely
install bolts by
hand
STEP 5: Loosely
install nuts by hand
STEP 6: Torque to
50 ft-lb (68 Nm)
STEP 7: Loosely
install nuts by hand
STEP 8: Torque to
50 ft-lb (68 Nm)
STEP 9: Torque to
37 ft-lb (50 Nm)
Driven Clutch Retaining
Fastener
43 ft-lbs (58 Nm)
Drive Clutch Retaining
Fastener
96 ft-lbs (130 Nm)
Outer PVT Cover
Fasteners
35 in-lbs (4 Nm)
Drive Clutch Cover
Fastener
100 in-lbs (11 Nm)
Driven Clutch Helix
Fastener
32 ft-lbs (44 Nm)
PVT Outlet Duct Fastener
54 in-lbs (6 Nm)
PVT Inlet Duct Fastener
54 in-lbs (6 Nm)
PVT Hose Adapter
Clamps
35 in-lbs (4 Nm)
PVT Inlet Hose Clamp 35 in-lbs (4 Nm)
PVT Cover to
Transmission Fastener
50 ft-lbs (68 Nm)
Shift Weight Fastener 20 in-lb (2 Nm)
CHAPTER 6 — TRANSMISSION
PART DESCRIPTION
TORQUE
SPECIFICATION
Solenoid
25 ft-lbs (34 Nm)
Bearing Cover Retaining
Fastener
9 ft-lbs (12 Nm)
Snorkel Locking Fastener 9 ft-lbs (12 Nm)
Differential Cover
Fastener
26 ft-lbs (35 Nm)
Fork Retainer Fastener
9 ft-lbs (12 Nm)
Transmission Fill / Drain
Plug
12 ft-lbs (16 Nm)
Bell Crank Nut
14 ft-lbs (19 Nm)
Speed Sensor 10 ft-lbs (14 Nm)
Rear Mount Bracket
Fastener
20 ft-lbs (27 Nm)
Rear Transmission Mount
Bracket Fastener
40 ft-lbs (54 Nm)
Rear Transmission Mount
Fastener
22 ft-lbs (30 Nm)
Transmission Mount to
Engine Fastener
37 ft-lbs (50 Nm)
Transmission Case
Fastener
20 ft-lbs (27 Nm)
Sector Cover Fastener
10 ft-lbs (14 Nm)
Park Plate Fastener
9 ft-lbs (12 Nm)
