External Air Inlet Filter Assembly (Part Number STD558)
Beginning in May 2014, we started supplying an external air
inlet filter assembly to improve the CIRAS-3 resistance to dirty,
dusty environments. As described above, the internal gas
circuit and optics are protected with several filters but this
external filter also provides added protection and can easily be
changed. It easily connects to the CIRAS-3 “AIR IN” port as
shown below:
This assembly is supplied with a filter element, 48 um, blue
(Part Number STD556) as standard. For severe dusty
environments, we recommend the filter element, 10 um, Yellow
(Part Number STD555).
Re-Order Information
Part Number
Description
10045-1
Filter Assembly (Air Supply)
30124-1
Air Filter, 5 micron
30124-2
Air Filter, 25 micron
STD558
External Air Inlet Filter Assembly
STD555
Filter Element, 10 um, Yellow (For severe dusty environments)
STD556
Filter Element, 48 um, Blue
Desiccants and Absorber Columns
The CIRAS-3 has two well labeled absorber column assemblies (total of 4 absorber columns) for analyzer
Zero and CO
2
and H
2
O control.
